- Model: EKG-1206
- Units in Stock: 9
|
$845.00
Features:
Six channel digital ECG machine with interpretation
Simultaneous acquisition of 12-lead ECG signal
Manual/Auto/Arrhythmia analysis modes
Real time ECG, 20 patients cases
Multiple printing modes
112mm 3/6-ch format recording
320x240 graphic, 3.8 inch LCD
High resolution thermal printing system
High resolution digital filter
Built-in USB or RS232, optional PC-ECG software
AC/DC power, built-in rechargeable Ni-MH battery
Light weight with handle, convenient for use
Specification:
Safety standard IEC60601-1 class I, type CF
Lead Standard 12 Leads, Lead change automatically
Resolution 12 bit / 1000Hz
Operation mode Manual/Auto/Analysis modes
Filter AC, EMG filter
Drift filter Anti-drift system
Input circuit Floating; Protection against Defibrillator effect
CMRR >100dB (with filter)
Input circuit current <0.1μA
Input impedance ≥50MΩ
Calibrating voltage 1mV±3%
Frequency response 0.05Hz~160Hz (IEC)
Time constant >3.2seconds
Noise level ≤15Vp-p
Threshold ≤20μV
Sensitivity Auto 2.5, 5, 10, 20, 40mm/mV
Recording system High resolution thermal printer
Paper speed 25, 50mm/s±3%
Recording paper 112mmx20m, roll/fold paper
Power supply
AC: 220V / 110V, 50/60Hz
DC: 14.4V rechargeable NI-Ion battery (2200mAh)
LCD display 320x240 graphic, 3.8 inch LCD
Dimensions 285x265x72mm
Weight 2.5kg
